50Hz Off-grid Inverter Off Grid 3KW to 15KW Low Frequency Hybrid Solar Inverter With MPPT Charge Controller for Home
Highly compatible with it
Various types of batteries
Battery voltage: 12V, 24V, 48V, 60V, 72V, 96V
- Overview
- Recommended Products
Solar MPPT inverse control integrated machine | |||||||
Model No. |
A1 |
A2 |
A3 |
A4 |
A5 |
A6 |
A7 |
Rated power |
3000W |
5000W |
6000W |
8000W |
10000W |
12000W |
15000W |
Peak power |
9000W |
15000W |
18000W |
24000W |
30000 |
36000 |
45000W |
Battery Voltage |
24V/48V |
24V/48V |
24/48V |
48/96V |
48V/96V |
48V/96V |
48V/96V |
Net Weight |
27KG |
32KG |
34KG |
38KG |
43KG |
56KG |
60KG |
Chassis Size |
270*490*470 |
||||||
Packing Size |
350*530*580mm |
||||||
Conversion time |
≤5ms |
||||||
Input Voltage |
220VAC ( 土15% ) |
||||||
Output voltage |
Mains mode: synchronized with mains; inverter mode: 220 VAC (earth 5%) |
||||||
Output Frequency |
Mains mode: synchronized with mains; Inverter mode: 50Hz, 0.5 % earth |
||||||
Display |
LCD display |
||||||
Protection mode |
Intelligent detection, overload, overvoltage, overcurrent, high voltage, low voltage, high temperature, low temperature and other automatic protection |
||||||
Battery type |
Lead-acid batteries, gel batteries, lithium iron phosphate batteries, ternary lithium batteries |
||||||
Operation mode |
Battery priority mode, utility priority mode, energy saving mode, unattended mode |
||||||
Utility charging |
0-30A |
||||||
